PIAGGIO Fly - Page 48

Level indicators and enable signals section
START PERMISSIVE BUTTONS AND LEVEL INDICATORS
Specification
Desc./Quantity
1 Magneto flywheel
2 Voltage regulator
3 Key switch
4 Main fuse 7,5A
5 Brake light filament 12V - 21W
6 Front and rear brake light button
7 Start up button
8 Starter motor
9 Remote starter switch
10 Battery 12V - 4Ah
11 Low oil warning light 12V - 1.2W
12 Oil level sender
13 Low fuel warning light 12V - 1.2W
14 Fuel gauge
15 Fuel level sender
Electrical system Fly
ELE SYS - 48
