020477Y 37 mm adaptor
Removing the driven pulley shaft bearing
- Remove the seeger ring
- Heat the engine crankcase but do not direct the
hot air towards the bearing
- Extract the driven pulley shaft together with the
bearing with a few mallet blows
Engine Fly
ENG - 72

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO Fly and is the answer not in the manual?

PIAGGIO Fly Specifications

General IconGeneral
TransmissionAutomatic CVT
Front BrakeDisc
Rear BrakeDrum
StarterElectric and kick
Engine TypeSingle cylinder, 4-stroke
Cooling SystemAir-cooled
Front SuspensionTelescopic fork
Front Tire120/70-12
Fuel SystemCarburetor
