- Work on the screws shown in the figure.
- When refitting, secure to the prescribed torque.
Locking torques (N*m)
Stand screw torque 18.5 to 19 Nm
Centre-stand bolt removal from mounting bracket
- Remove the stand support bracket from the en-
gine.
- Drill a 5 mm hole in the bracket so that the pin
«P» can come out.
Fly Suspensions
SUSP - 99
