Refitting
- When refitting, tighten the nuts to the prescribed torque.
- Bleed the system.
N.B.
WHILE REFITTING, REPLACE THE COPPER GASKETS ON THEIR FITTINGS.
Locking torques (N*m)
Oil bleed screw 7 ÷ 10 Calliper tightening screw 24 ÷ 27 Brake fluid pipe-calliper fitting 19 ÷ 24
See also
Front
Front brake disc
Removal
- Remove the front wheel undoing the axle clamp-
ing.
- Undo the five disc clamps.
Locking torques (N*m)
Disc tightening screw 8 ÷ 10
Refitting
-When refitting, position the disc correctly making sure that it rotates in the right direction.
Locking torques (N*m)
Disc tightening screw 8 - 12
MSS ZIP 100 4T Braking system
BRAK SYS - 139
