PIAGGIO ZIP 4T - Steering Column Bearings

To Next Page

To Previous Page

Steering column bearings

STEERING FIFTH WHEELS

Code

Action Duration

1 003051 Complete fork - Replacement

2 003002 Steering fifth wheels - Replacement

3 003073 Steering clearance - Adjustment

MSS ZIP 100 4T Time

TIME - 175
