Helmet bay
- Remove the side fairings
- Remove the helmet compartment by undoing the
4 screws indicated in the figure
Fuel tank
- Remove the side fairings
- Remove the rear mudguard
- Remove the crews shown in the photograph
- Remove the shock absorber upper clamping in
order to create the necessary space to take out the
tank.
Chassis MSS ZIP 100 4T
CHAS - 148

PIAGGIO ZIP 4T Specifications

General

Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Hydraulic shock absorber
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Length	1, 700 mm
Width	680 mm
Engine Type	Single cylinder, 4-stroke
Transmission	CVT
Top Speed	45 km/h
Max Power	2.6 kW at 7, 500 rpm
Weight	89 kg (dry)
