Rear wheel

REAR WHEEL

Code

Action Duration

1 004126 Rear wheel tyre - Replacement

2 001071 Rear wheel rim - Removal and Refit-

ting

3 001016 Rear wheel - Replacement

4 002002 Rear brake pads/shoes - Repl.

Time MSS ZIP 100 4T

TIME - 182
