Stores code
Description
020449Y
Piston position check support
020450Y
Camshaft fitting/removal tool
020451Y
Driving pulley lock wrench
020452Y
Tube for removing and refitting the driven
pulley shaft
020456Y
Ø 24 mm adaptor
020565Y
Flywheel lock calliper spanner
020498Y
Pin lock fitting tool
Tooling
MSS ZIP 100 4T
TOOL - 24
23
25
