Pilous ARG 200 plus - Oil Damper Assembly

11.3. Oil Damper Assembly
1
2
3
4
5
7
8
5
6
7
8
9
Pos
1
2
3
4
5
6
7
8
9
Order number
006462
024930
024927
017218
014992
014994
014996
014998
021041
020916
006571
006573
020915
006587
001386
001429
001431
001430
001431
001881
001696
007141
020907
001986
002277
003569
006953
Name
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Gibbet
Hydraulic cylinder
Hydraulic cylinder
Hydraulic cylinder
Butterfly valve
Hydraulics pin
Retaining ring KR 12, outer
Retaining ring KR 20, outer
Retaining ring KR 15, outer
Retaining ring KR 20, outer
Hydraulic hose DN 6x2500, 90
Hydraulic hose DN 8x2500, 90, M16x1.5, 40bar
Hydraulic hose DN 8x3000, 90, M16x1.5, 40bar
Hydraulic hose DN 8x4500, 90 16, ARG330
Straight connector GES 8L/R
Straight connector GES 10L/R
Hydraulic oil HV 46
Adjustable connector EWSD 10L
Type ARG
200+
235
235+
260+E
260
260+
300
300+
330
330+
200+,235, 260+E
260,300
330
200-330
200-300
200-300
330
200-300
330
200+, 235
260
300
330
200-235
260-330
200-330
330
Pcs
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
2
2
2
1 l
1
ver. 1.11.2018
