Pilous ARG 200 plus - Vice Assembly in ARG 200 Plus; Vice Assembly in ARG 235, 235 Plus, ARG 260 Plus E

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
14
ver. 1.11.2018
Order number
014560
017936
016263
014555
014556
014557
014558
018094
011363
011364
011365
Name
Vice body
Vice body
Movable jaw
Trapezoidal nut quick-clamping
Vice guidance, quick
Movable jaw plate
Groove bar
Trapezoidal screw
Head, quick-clamping
Spacer ring
Support ring
Pcs
1
1
1
1
1
1
1
1
1
1
1
Pos
1
2
3
4
5
6
7
8
9
10
Type ARG
235+,260+E
235
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
Order number
001365
011366
002111
001720
001711
001617
001712
014240
009552
002642
022982
Name
Quick-clamping excentr.
Quick-clamping lever plus
Vice handwheel with a crank
Ball bearing 6203-2Z
Ball, bearing
Worm Allen bolt, M8x30
Locking nut M8 8 zn
Tight spring 10e7x8x40
5x40 flexible pin
6x40 flexible pin
6x28 flexible pin
Pcs
1
1
1
2
6
6
6
1
2
1
1
Pos
11
12
13
14
15
16
17
18
19
20
21
Type ARG
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
235,235+,260+E
19
2
7
5
4
1
3
6
ver. 1.1.2016
Order number
009427
009416
009446
006862
009055
004241
009146
Name
Vice body plus
Vice cylinder
Movable jaw plate plus
Star nut
Adjustable lever, M8x50
5x28 flexible pin
Rectangular nut
Pcs
1
1
1
1
1
1
1
Pos
1
2
3
4
5
6
7
Type ARG
200+
200+
200+
200+
200+
200+
200+
11.4.3. Vice Assembly in ARG 200 plus
11.4.4. Vice Assembly in ARG 235, 235 plus, ARG 260 plus E
