Pilous ARG 200 plus - Page 55

PULSE GENERATOR SETTINGS 6 BAR (90 PSI)
66 PULSES
PER MINUTE
37 pulses per minute 21 pulses per minute 13 pulses per minute 10 pulses per minute 6 pulses per minute 5 pulses per minute
4 pulses per minute 3 pulses per minute 2,5 pulses per minute 2 pulses per minute 1,5 pulses per minute 1 pulses per minute
DOSING PUMP SETTINGS
Piston vacuum pump doses the lubricant accurately and under
high pressure.
MAX
GROOVE 1
GROOVE 2
GROOVE 3
GROOVE 4
GROOVE 5
GROOVE 6
GROOVE 7
GROOVE No.
1
2
3
4
5
6
7
CLICK
0
4
8
12
16
18
20
SUPPLIED VOLUME/STROKE
3
41 mm
3
30 mm
3
23 mm
3
16 mm
3
9 mm
3
2 mm
3
0 mm
