PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 39
Unit types with UB 48-240 VAC/DC
} U
B
: 48 – 240 VAC/DC; Order no. 750134, 751134
10000
1000
5000
100
500
10
50
0,1 0,5 1 2 3 4 5 6 8 10
DC-1: 24VDC-1: 24V
AC-1: 230VAC-1: 230V
AC-15: 230VAC-15: 230V
DC-13: 24VDC-13: 24V
Number of operating cycles x 1000
Switching current (A)
Fig.: Service life graphs at 24 VDC and 230 VAC
Number of cycles x 1000
Switching current (A)
Fig.: Service life graphs at 110 VDC
