Pilz PNOZ s4 User Manual

PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 22
Technical details Order no. 750104, 750134, 751104
General 750104 750134 751104
Certifications
CCC, CE, EAC, KOSHA,
TÜV, UKCA, cULus Lis-
ted
CCC, CE, EAC, KOSHA,
TÜV, UKCA, cULus Lis-
ted
CCC, CE, EAC, KOSHA,
TÜV, UKCA, cULus Lis-
ted
Electrical data 750104 750134 751104
Supply voltage
Voltage 24 V 48 - 240 V 24 V
Kind DC AC/DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) – 5 VA –
Output of external
power supply (DC) 2,5 W 2,5 W 2,5 W
Frequency range AC – 50 - 60 Hz –
Residual ripple DC 20 % 160 % 20 %
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 0,5 A – 0,5 A
Pulse duration, A1 5 ms – 5 ms
Inputs 750104 750134 751104
Quantity 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 50 mA
Start circuit DC 50 mA 50 mA 50 mA
Feedback loop DC 50 mA 50 mA 50 mA
Max. inrush current im-
pulse
Current pulse, input cir-
cuit 0,2 A 0,2 A 0,2 A
Pulse duration, input
circuit 100 ms 100 ms 100 ms
Current pulse, feed-
back loop 0,2 A 0,2 A 0,2 A
Pulse duration, feed-
back loop 15 ms 15 ms 15 ms
Current pulse, start cir-
cuit 0,2 A 0,2 A 0,2 A
Pulse duration, start
circuit 15 ms 15 ms 15 ms
Min. input resistance at
power-on 110 Ohm 110 Ohm 110 Ohm

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
