Pilz PNOZ s4 User Manual

PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 29
Technical details Order no. 751134, 751184
General 751134 751184
Certifications
CCC, CE, EAC, KOSHA, TÜV,
UKCA, cULus Listed
CCC, CE, EAC, KOSHA, TÜV,
UKCA, cULus Listed
Electrical data 751134 751184
Supply voltage
Voltage 48 - 240 V 24 V
Kind AC/DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 5 VA –
Output of external power supply
(DC) 2,5 W 2,5 W
Frequency range AC 50 - 60 Hz –
Residual ripple DC 160 % 20 %
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 – 0,5 A
Pulse duration, A1 – 5 ms
Inputs 751134 751184
Quantity 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 50 mA 50 mA
Feedback loop DC 50 mA 50 mA
Max. inrush current impulse
Current pulse, input circuit 0,2 A 0,2 A
Pulse duration, input circuit 100 ms 100 ms
Current pulse, feedback loop 0,2 A 0,2 A
Pulse duration, feedback loop 15 ms 15 ms
Current pulse, start circuit 0,2 A 0,2 A
Pulse duration, start circuit 15 ms 15 ms
Min. input resistance at power-on 110 Ohm 110 Ohm

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
