Pilz PNOZ s4 User Manual

PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 30
Inputs 751134 751184
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Single-channel at UB AC 30 Ohm –
Dual-channel without detection
of shorts across contacts at UB
DC 30 Ohm 60 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 30 Ohm –
Dual-channel with detection of
shorts across contacts at UB DC 30 Ohm 30 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 30 Ohm –
Semiconductor outputs 751134 751184
Quantity 1 1
Voltage 24 V 24 V
Current 20 mA 20 mA
Residual current at "0" signal 0,1 mA 0,1 mA
Max. internal voltage drop – 5 V
Conditional rated short circuit cur-
rent 100 A 100 A
Lowest operating current 0 mA 0 mA
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
Relay outputs 751134 751184
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
in accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. power 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. power 0,04 W 0,04 W
Max. power 150 W 150 W

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
