PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 31
Relay outputs 751134 751184
Utilisation category of auxiliary con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. power 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. power 0,04 W 0,04 W
Max. power 150 W 150 W
Utilisation category
in accordance with the standard EN 60947-5-1 EN 60947-5-1
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 3 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 4 A 5 A
Utilisation category of auxiliary con-
tacts
AC15 at 230 V 230 V
Max. current 3 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 4 A 5 A
Utilisation category in accordance
with UL
Voltage 240 V AC G.U. (same polarity) 240 V AC G.U. (same polarity)
with current 6 A 6 A
Voltage 24 V DC G. U. 24 V DC G. U.
with current 6 A 6 A
External contact fuse protection,
safety contacts
in accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 66 A²s 260 A²s
Blow-out fuse, quick 6 A 10 A
Blow-out fuse, slow 4 A 6 A
Blow-out fuse, gG 6 A 10 A
Circuit breaker 24V AC/DC,
characteristic B/C 4 A 6 A

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
