PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 16
} : Gate open
} : Gate closed
Application examples
Emergency stop
} Dual-channel
} with detection of shorts across contacts
} Monitored start
} falling edge with feedback loop monitoring
,Q ,Q
$$
PRGH
3RZHU
,Q
,Q
2XW
6WDUW
)DXOW
312=V&
9'&QR
QF
312=V&9'&QRQF
3,/=
;

$
;

$
;

6

6
;

6

6

6
;

<


6




6
6WDUW


)HHGEDFN/RRS
9'&
9

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
