Pilz PNOZ s4 User Manual

PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 28
Mechanical data 750104 750134 751104
Torque setting with screw
terminals 0,5 Nm 0,5 Nm –
Stripping length with
screw terminals 8 mm 8 mm –
Conductor cross section
with spring-loaded termin-
als: Flexible with/without
crimp connector – –
0,2 - 2,5 mm², 24 - 12
AWG
Spring-loaded terminals:
Terminal points per con-
nection – – 2
Stripping length with
spring-loaded terminals – – 9 mm
Dimensions
Height 98 mm 98 mm 100 mm
Width 22,5 mm 22,5 mm 22,5 mm
Depth 120 mm 120 mm 120 mm
Weight 185 g 210 g 185 g
Where standards are undated, the 2022-09 latest editions shall apply.

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
