Environmental data 750104 750134 751104
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2, EN 61000-6-4,
EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61000-6-4,
EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61000-6-4,
EN 61326-3-1
Vibration
in accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
in accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage 4 kV 4 kV 4 kV
Protection type
Housing IP40 IP40 IP40
Terminals IP20 IP20 IP20
Mounting area (e.g.
control cabinet) IP54 IP54 IP54
Mechanical data 750104 750134 751104
Mounting position Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles
Material
Bottom PC PC PC
Front PC PC PC
Top PC PC PC
Connection type Screw terminal Screw terminal Spring-loaded terminal
Mounting type plug-in plug-in plug-in
Conductor cross section
with screw terminals
1 core flexible
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG –
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG –
2 core with the same
cross section, flexible
without crimp connect-
ors or with TWIN crimp
connectors
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG –

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
