Pilz PNOZ X1 User Manual

PNOZ X1
Operating Manual PNOZ X1
19045-EN-10
| 13
Technical details
General
Certifications CCC, CE, EAC (Eurasian), TÜV, cULus Listed
Electrical data
Supply voltage
Voltage 24 V
Kind AC/DC
Voltage tolerance -15 %/+10 %
Output of external power supply (AC) 4 VA
Output of external power supply (DC) 2 W
Frequency range AC 50 - 60 Hz
Residual ripple DC 160 %
Duty cycle 100 %
Max. inrush current impulse
Current pulse, A1 2,5 A
Pulse duration, A1 5 ms
Inputs
Number 1
Voltage at
Input circuit DC 24 V
Start circuit DC 24 V
Feedback loop DC 24 V
Current at
Input circuit DC 70 mA
Start circuit DC 40 mA
Feedback loop DC 40 mA
Max. overall cable resistance Rlmax
Single-channel at UB DC 30 Ohm
Single-channel at UB AC 30 Ohm
Relay outputs
Number of output contacts
Safety contacts (N/O), instantaneous 3
Auxiliary contacts (N/C) 1
Max. short circuit current IK 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1

Pilz PNOZ X1 Specifications

General

Type	Safety Relay
Supply Voltage	24 VDC
Auxiliary Contacts	1 N/C
Width	45 mm
Mounting	DIN Rail
Number of safety contacts	2
Stop Category	0
Height	87 mm
Depth	121 mm
Rated current	6 A
Protection class	IP20
Safety Contacts	2 N/O
Operating Temperature Range	-10°C to +55°C
Weight	200 g
