Pilz PNOZ X10 User Manual

PNOZ X10
Operating Manual PNOZ X10
19554-EN-09
| 19
Times 774700 774701 774703
Switch-on delay
With automatic start
typ. 180 ms 180 ms 180 ms
With automatic start
max. 250 ms 250 ms 250 ms
With automatic start
after power on typ. 200 ms 200 ms 200 ms
With automatic start
after power on max. 300 ms 300 ms 300 ms
With manual start typ. 200 ms 200 ms 200 ms
With manual start max. 250 ms 250 ms 250 ms
With monitored start
typ. 150 ms 150 ms 150 ms
With monitored start
max. 200 ms 200 ms 200 ms
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms 20 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 170 ms 170 ms 170 ms
With power failure max. 250 ms 250 ms 250 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms 50 ms 50 ms
After power failure 300 ms 300 ms 300 ms
Min. start pulse duration
with a monitored start 50 ms 50 ms 50 ms
Supply interruption before
de-energisation 35 ms 35 ms 35 ms
Environmental data 774700 774701 774703
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
Vibration
In accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
