Pilz PNOZ X3 User Manual

PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
16
Technical details
Order no. 774310 – 774312
See below for more order numbers
General 774310 774311 774312
Approvals
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
Electrical data 774310 774311 774312
Supply voltage
Voltage 24 V 42 V 48 V
Kind AC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) 5 VA 5 VA 5 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (DC) 2,5 W 2,5 W 2,5 W
Residual ripple DC 160 % 160 % 160 %
Duty cycle 100 % 100 % 100 %
Inputs 774310 774311 774312
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 50 mA
Start circuit DC 35 mA 35 mA 35 mA
Feedback loop DC 20 mA 20 mA 20 mA
Min. input resistance at
power-on
130 Ohm 130 Ohm 130 Ohm
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 150 Ohm 150 Ohm 150 Ohm
Single-channel at UB
AC 180 Ohm 180 Ohm 180 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 15 Ohm 15 Ohm 15 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC 30 Ohm 30 Ohm 30 Ohm

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
