PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
33
} Contact service life: 4 000 000 cycles
Provided the application to be implemented requires fewer than 4 000 000 cycles, the PFH
value (see Technical details) can be used in the calculation.
To increase the service life, sufficient spark suppression must be provided on all output
contacts. With capacitive loads, any power surges that occur must be noted. With DC con-
tactors, use flywheel diodes for spark suppression.
Order reference
Product type Features Connection type Order no.
PNOZ X3 24 VAC; 24 VDC Screw terminals 774 310
PNOZ X3 42 VAC; 24 VDC Screw terminals 774 311
PNOZ X3 48 VAC; 24 VDC Screw terminals 774 312
PNOZ X3 110 VAC; 24 VDC Screw terminals 774 314
PNOZ X3 115 VAC; 24 VDC Screw terminals 774 315
PNOZ X3 120 VAC; 24 VDC Screw terminals 774 316
PNOZ X3 230 VAC; 24 VDC Screw terminals 774 318
PNOZ X3 240 VAC; 24 VDC Screw terminals 774 319
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/support/downloads.
Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost-
fildern, Germany

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
