Pilz PNOZ X3 User Manual

PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
19
Conventional thermal
current while loading
several contacts
774310 774311 774312
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A 8 A 8 A
Conv. therm. current
with 2 contacts 8 A 8 A 8 A
Conv. therm. current
with 3 contacts
7 A 7 A 7 A
Times 774310 774311 774312
Switch-on delay
With automatic start
typ. 250 ms 250 ms 250 ms
With automatic start
max. 500 ms 500 ms 500 ms
With automatic start
after power on typ. 280 ms 280 ms 280 ms
With automatic start
after power on max. 550 ms 550 ms 550 ms
With monitored start
typ. 35 ms 35 ms 35 ms
With monitored start
max. 50 ms 50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms 15 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 50 ms 50 ms 50 ms
With power failure max. 70 ms 70 ms 70 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms 50 ms 50 ms
After power failure 100 ms 100 ms 100 ms
Waiting period with a
monitored start
300 ms 300 ms 300 ms
Min. start pulse duration
with a monitored start
30 ms 30 ms 30 ms
Supply interruption before
de-energisation
20 ms 20 ms 20 ms
Simultaneity, channel 1
and 2 max.
∞ ∞ ∞
Environmental data 774310 774311 774312
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -20 - 55 °C -20 - 55 °C -20 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
