PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
30
Times 774318 774319
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 50 ms 50 ms
With power failure max. 70 ms 70 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 100 ms 100 ms
Waiting period with a monitored
start
300 ms 300 ms
Min. start pulse duration with a
monitored start
30 ms 30 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 774318 774319
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -20 - 55 °C -20 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 12015, EN 12016, EN
60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 12015, EN 12016, EN
60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 3 3
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
Protection type
Housing IP40 IP40
Terminals IP20 IP20
Mounting area (e.g. control cab-
inet)
IP54 IP54
Mechanical data 774318 774319
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
