PNOZ X8P
Operating Manual PNOZ X8P
19820-EN-10
| 18
Technical details Order no. 777760-777768
General 777760 777764 777768
Certifications
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 777760 777764 777768
Supply voltage
Voltage 24 V 110 V 230 V
Kind DC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) – 6,5 VA 6,5 VA
Output of external
power supply (DC) 2,5 W – –
Frequency range AC – 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % – –
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 10 A – –
Pulse duration, A1 0,5 ms – –
Inputs 777760 777764 777768
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 45 mA 40 mA 40 mA
Start circuit DC 50 mA 60 mA 60 mA
Feedback loop DC 50 mA 60 mA 60 mA
Min. input resistance at
power-on 89 Ohm 89 Ohm 89 Ohm
