PNOZ X8P
Operating Manual PNOZ X8P
19820-EN-10
| 24
Technical details Order no. 787760-787764
General 787760 787764
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 787760 787764
Supply voltage
Voltage 24 V 110 V
Kind DC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) – 6,5 VA
Output of external power supply
(DC) 2,5 W –
Frequency range AC – 50 - 60 Hz
Residual ripple DC 160 % –
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 10 A –
Pulse duration, A1 0,5 ms –
Inputs 787760 787764
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 45 mA 40 mA
Start circuit DC 50 mA 60 mA
Feedback loop DC 50 mA 60 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 100 Ohm –
Single-channel at UB AC – 100 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 200 Ohm –
Dual-channel without detection
of shorts across contacts at UB
AC – 200 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 16 Ohm –
Dual-channel with detection of
shorts across contacts at UB AC – 28 Ohm
Semiconductor outputs 787760 787764
Number 2 2
