Pilz PNOZ X8P User Manual

PNOZ X8P
Operating Manual PNOZ X8P
19820-EN-10
| 25
Semiconductor outputs 787760 787764
Voltage 24 V 24 V
Current 50 mA 50 mA
External supply voltage 24 V 24 V
Voltage tolerance -20 %/+20 % -20 %/+20 %
Residual current at "0" signal 0,1 mA 0,1 mA
Max. internal voltage drop 4 V 4 V
Conditional rated short circuit cur-
rent 100 A 100 A
Lowest operating current 0 mA 0 mA
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
Relay outputs 787760 787764
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Auxiliary contacts (N/C) 2 2
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
Utilisation category of auxiliary con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
