Pilz PNOZ X8P User Manual

PNOZ X8P
Operating Manual PNOZ X8P
19820-EN-10
| 27
Conventional thermal current
while loading several contacts
787760 787764
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 8 A –
Conv. therm. current with 2 con-
tacts 8 A –
Conv. therm. current with 3 con-
tacts 7 A –
Times 787760 787764
Switch-on delay
With automatic start typ. 160 ms 175 ms
With automatic start max. 200 ms 220 ms
With automatic start after power
on typ. 185 ms 200 ms
With automatic start after power
on max. 220 ms 250 ms
With manual start typ. 190 ms 190 ms
With manual start max. 250 ms 250 ms
With monitored start typ. 130 ms 130 ms
With monitored start max. 180 ms 180 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 100 ms 160 ms
With power failure max. 200 ms 220 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 180 ms 250 ms
Min. start pulse duration with a
monitored start 30 ms 30 ms
Supply interruption before de-ener-
gisation 35 ms 35 ms
Environmental data 787760 787764
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
