Operating Manual PNOZ X8P
19820-EN-10
| 31
Relay outputs 787768 787770
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Blow-out fuse, gG 10 A 10 A
Circuit breaker 24V AC/DC,
characteristic B/C 6 A 6 A
External contact fuse protection,
auxiliary contacts
Max. melting integral 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Blow-out fuse, gG 10 A 10 A
Circuit breaker 24 V AC/DC,
characteristic B/C 6 A 6 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal current
while loading several contacts
787768 787770
Ith per contact at UB AC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 8 A 8 A
Conv. therm. current with 2 con-
tacts 7,3 A 7,3 A
Conv. therm. current with 3 con-
tacts 6 A 6 A
Times 787768 787770
Switch-on delay
With automatic start typ. 175 ms 175 ms
With automatic start max. 220 ms 220 ms
With automatic start after power
on typ. 200 ms 200 ms
With automatic start after power
on max. 250 ms 250 ms
With manual start typ. 190 ms 190 ms
With manual start max. 250 ms 250 ms
With monitored start typ. 130 ms 130 ms
With monitored start max. 180 ms 180 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 160 ms 160 ms
With power failure max. 220 ms 220 ms
