Pilz PNOZ XV3.1P User Manual

PNOZ XV3.1P
Operating Manual PNOZ XV3.1P
20516-EN-09
| 18
Technical details Order no. 777520-777525
General 777520 777522 777525
Certifications
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 777520 777522 777525
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (DC) 4,5 W 4,5 W 4,5 W
Residual ripple DC 160 % 160 % 160 %
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 5 A 5 A 5 A
Pulse duration, A1 1 ms 1 ms 1 ms
Inputs 777520 777522 777525
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 50 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 3 mA 3 mA 3 mA
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 100 Ohm 100 Ohm 100 Ohm
Dual-channel without
detection of shorts
across contacts at UB
DC 120 Ohm 120 Ohm 120 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 10 Ohm 10 Ohm 10 Ohm
Relay outputs 777520 777522 777525
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 3 3 3
Safety contacts (N/O),
delayed 2 2 2
Auxiliary contacts (N/C) 1 1 1
