Operating Manual PNOZ XV3.1P
20516-EN-09
| 23
Mechanical data 777520 777522 777525
Material
Bottom PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0 ABS UL 94 V0
Top PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Connection type Screw terminal Screw terminal Screw terminal
Mounting type plug-in plug-in plug-in
Conductor cross section
with screw terminals
1 core flexible
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG
2 core with the same
cross section, flexible
without crimp connect-
ors or with TWIN crimp
connectors
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
Torque setting with screw
terminals 0,5 Nm 0,5 Nm 0,5 Nm
Stripping length with
screw terminals 8 mm 8 mm 8 mm
Dimensions
Height 94 mm 94 mm 94 mm
Width 90 mm 90 mm 90 mm
Depth 121 mm 121 mm 121 mm
Weight 510 g 510 g 500 g
Where standards are undated, the 2020-07 latest editions shall apply.
Technical details Order no. 777530-777538
General 777530 777532 777538
Certifications
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 777530 777532 777538
Supply voltage
Voltage 24 - 240 V 24 - 240 V 24 - 240 V
Kind AC/DC AC/DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) 8,5 VA 8,5 VA 8,5 VA
Output of external
power supply (DC) 5 W 5 W 5 W
Frequency range AC 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % 160 % 160 %
Duty cycle 100 % 100 % 100 %
