PNOZ XV3.1P
Operating Manual PNOZ XV3.1P
20516-EN-09
| 37
Technical details Order no. 787532-787538
General 787532 787538
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 787532 787538
Supply voltage
Voltage 24 - 240 V 24 - 240 V
Kind AC/DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 8,5 VA 8,5 VA
Output of external power supply
(DC) 5 W 5 W
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % 160 %
Duty cycle 100 % 100 %
Inputs 787532 787538
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 40 mA 40 mA
Start circuit DC 40 mA 40 mA
Feedback loop DC 3 mA 3 mA
Max. overall cable resistance Rl-
max
Single-channel at UB DC 150 Ohm 150 Ohm
Single-channel at UB AC 150 Ohm 150 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 200 Ohm 200 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 200 Ohm 200 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 20 Ohm 20 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 20 Ohm 20 Ohm
Relay outputs 787532 787538
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Safety contacts (N/O), delayed 2 2
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
