Operating Manual PNOZ XV3.1P
20516-EN-09
| 36
Environmental data 787520 787522 787530
Vibration
In accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
In accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage 4 kV 4 kV 4 kV
Protection type
Housing IP40 IP40 IP40
Terminals IP20 IP20 IP20
Mounting area (e.g.
control cabinet) IP54 IP54 IP54
Mechanical data 787520 787522 787530
Mounting position Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles
Material
Bottom PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0 ABS UL 94 V0
Top PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Connection type Spring-loaded terminal Spring-loaded terminal Spring-loaded terminal
Mounting type plug-in plug-in plug-in
Conductor cross section
with spring-loaded termin-
als: Flexible with/without
crimp connector
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
Spring-loaded terminals:
Terminal points per con-
nection 2 2 2
Stripping length with
spring-loaded terminals 8 mm 8 mm 8 mm
Dimensions
Height 101 mm 101 mm 101 mm
Width 90 mm 90 mm 90 mm
Depth 121 mm 121 mm 121 mm
Weight 510 g 510 g 535 g
Where standards are undated, the 2020-07 latest editions shall apply.
