PNOZ XV3.1P
Operating Manual PNOZ XV3.1P
20516-EN-09
| 30
Technical details Order no. 787520-787530
General 787520 787522 787530
Certifications
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 787520 787522 787530
Supply voltage
Voltage 24 V 24 V 24 - 240 V
Kind DC DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) – – 8,5 VA
Output of external
power supply (DC) 4,5 W 4,5 W 5 W
Frequency range AC – – 50 - 60 Hz
Residual ripple DC 160 % 160 % 160 %
Duty cycle 100 % 100 % 100 %
Max. inrush current im-
pulse
Current pulse, A1 5 A 5 A –
Pulse duration, A1 1 ms 1 ms –
Inputs 787520 787522 787530
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 40 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 3 mA 3 mA 3 mA
