Operating Manual PNOZ XV3.1P
20516-EN-09
| 31
Inputs 787520 787522 787530
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 100 Ohm 100 Ohm 150 Ohm
Single-channel at UB
AC – – 150 Ohm
Dual-channel without
detection of shorts
across contacts at UB
DC 120 Ohm 120 Ohm 200 Ohm
Dual-channel without
detection of shorts
across contacts at UB
AC – – 200 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 10 Ohm 10 Ohm 20 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC – – 20 Ohm
Relay outputs 787520 787522 787530
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 3 3 3
Safety contacts (N/O),
delayed 2 2 2
Auxiliary contacts (N/C) 1 1 1
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 2000 VA 2000 VA 2000 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 200 W 200 W 200 W
