Environmental data 777530 777532 777538
Airgap creepage
In accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage 4 kV 4 kV 4 kV
Protection type
Housing IP40 IP40 IP40
Terminals IP20 IP20 IP20
Mounting area (e.g.
control cabinet) IP54 IP54 IP54
Mechanical data 777530 777532 777538
Mounting position Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles
Material
Bottom PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0 ABS UL 94 V0
Top PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Connection type Screw terminal Screw terminal Screw terminal
Mounting type plug-in plug-in plug-in
Conductor cross section
with screw terminals
1 core flexible
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG
0,25 - 2,5 mm², 24 - 12
AWG
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG
0,25 - 1 mm², 24 - 16
AWG
2 core with the same
cross section, flexible
without crimp connect-
ors or with TWIN crimp
connectors
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
0,2 - 1,5 mm², 24 - 16
AWG
Torque setting with screw
terminals 0,5 Nm 0,5 Nm 0,5 Nm
Stripping length with
screw terminals 8 mm 8 mm 8 mm
Dimensions
Height 94 mm 94 mm 94 mm
Width 90 mm 90 mm 90 mm
Depth 121 mm 121 mm 121 mm
Weight 540 g 540 g 540 g
