Pilz PNOZ XV3.1P User Manual

PNOZ XV3.1P
Operating Manual PNOZ XV3.1P
20516-EN-09
| 24
Inputs 777530 777532 777538
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 40 mA 40 mA 40 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 3 mA 3 mA 3 mA
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 150 Ohm 150 Ohm 150 Ohm
Single-channel at UB
AC 150 Ohm 150 Ohm 150 Ohm
Dual-channel without
detection of shorts
across contacts at UB
DC 200 Ohm 200 Ohm 200 Ohm
Dual-channel without
detection of shorts
across contacts at UB
AC 200 Ohm 200 Ohm 200 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 20 Ohm 20 Ohm 20 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC 20 Ohm 20 Ohm 20 Ohm
Relay outputs 777530 777532 777538
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 3 3 3
Safety contacts (N/O),
delayed 2 2 2
Auxiliary contacts (N/C) 1 1 1
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
