Pilz PNOZmulti 2 User Manual

OverviewCommunicationoptions
OperatingManualCommunicationinterfaces
1002971EN03
10
2.3 CommunicationviaModbusTCP
FordataexchangewithModbus/TCP,thePNOZmulti2istheconnectionserver.Allthe
servicedataisdefinedinonedatarecord,towhichtheclienthasdirectaccess.
CommunicationwithModbus/TCPisdescribedindetailinthechapterentitledModbus/
TCP[ 51].
Thefollowingdevicecombinationsarepossible:
CommunicationModule Baseunit
PNOZmESETH[ 32]
PNOZmB0
INFORMATION
Ifvirtualinputs/outputsaretobedownloadedviathecommunicationmodule
(withoutusingafieldbusmodule),theinterface"Inputs/outputsthatare
downloadedviatheintegratedinterface"mustbeconfiguredinthehard
wareconfigurationinthePNOZmultiConfigurator.

Pilz PNOZmulti 2 Specifications

General

Brand	Pilz
Model	PNOZmulti 2
Category	Control Unit
Language	English
