Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
81
Processdata Profinet
I/OLEDs 12...27 19 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 3 1 0...3
Outputs 4...7 3 1 4...7
SystemLEDs 8...10 3 1 8...10
I/OLEDs 12...27 3 1 12...27
8.1.6.9 Processdataaddressing,2ndlefthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 22 3 0...3
Outputs 4...7 22 3 4...7
SystemLEDs 8...10 22 3 8...10
I/OLEDs 12...23 22 4 0...11
I/OLEDs 24...27 22 5 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2007 37...40
Outputs 4...7 0x2007 41...44
SystemLEDs 8...10 0x2007 45...47
I/OLEDs 12...27 0x2007 49...64
