6.5 ExamplesofClientsandServers
ThefollowingsubscriberscommunicateviaModbus/TCPorEthernet:
} DeviceswithServerrole:
– PNOZmESETH
– PNOZm1pETH
– PNOZmmc1pETH
} DeviceswithClientrole:
– PSSusystemintheautomationsystemPSS4000
– OperatorterminalPMI
} PCasprogrammingdeviceforPNOZmulti2,PSSusystemandPMI
ThePSSusystemandtheoperatorterminalPMIaccesstheconfigurablecontrolsystem
PNOZmulti2(Serverrole)simultaneously.
PC
192.168.1.60
PMI
192.168.1.10
PSSu-System
192.168.1.100
PNOZ m B0 +
PNOZ m ES ETH
192.168.1.110
PNOZ mm0.1p +
PNOZ mmc1p ETH
192.168.1.2
PNOZ m1p ETH
192.168.1.1
