Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
93
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
ID 0...12 0x200B 81...93
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput(1x)
ID 0...12 2150...2156 34400...34503
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
ID 0...12 36 0...12
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
ID 0...12 5 10 0...12
8.5 Projectdata
Theprojectdata,whichwasalsodefinedinthePNOZmultiConfigurator,consistsof60
Bytes.
8.5.1 Checksums
Byte AboutPNOZmultiConfigurator
0 Projectchecksum
e.g.checksumA1B2(hex:)
} Byte0:A1
} Byte1:B2
1
2
} Overallchecksum
3
4 Reserved
