Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
74
Processdata Profinet
I/OLEDs 12...27 4 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 2 2 0...3
Outputs 4...7 2 2 4...7
SystemLEDs 8...10 2 2 8...10
I/OLEDs 12...27 2 2 12...27
8.1.6.4 Processdataaddressing,3rdrighthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 21 6 0...3
Outputs 4...7 21 6 4...7
SystemLEDs 8...10 21 6 8...10
I/OLEDs 12...23 21 7 0...11
I/OLEDs 24...27 21 8 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2002 37...40
Outputs 4...7 0x2002 41...44
SystemLEDs 8...10 0x2002 45...47
I/OLEDs 12...27 0x2002 49...64
