Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
71
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 1 0...3
Outputs 4...7 1 4...7
SystemLEDs 8...10 1 8...10
I/OLEDs 12...27 1 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 1 1 0...3
Outputs 4...7 1 1 4...7
SystemLEDs 8...10 1 1 8...10
I/OLEDs 12...27 1 1 12...27
8.1.6.2 Processdataaddressing,1strighthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 21 0 0...3
Outputs 4...7 21 0 4...7
SystemLEDs 8...10 21 0 8...10
I/OLEDs 12...23 21 1 0...11
I/OLEDs 24...27 21 2 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2001 73...76
Outputs 4...7 0x2001 77...80
SystemLEDs 8...10 0x2001 81...83
