Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
72
Processdata SDOs
I/OLEDs 12...27 0x2001 85...100
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1060...1061 16960...16991
Outputs 4...7 1062...1063 16992...17023
SystemLEDs 8...10 1064...1065 17024...17047
I/OLEDs 12...27 1066...1073 17056...17183
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 3 0...3
Outputs 4...7 3 4...7
SystemLEDs 8...10 3 8...10
I/OLEDs 12...27 3 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 2 1 0...3
Outputs 4...7 2 1 4...7
SystemLEDs 8...10 2 1 8...10
I/OLEDs 12...27 2 1 12...27
