Pilz PNOZmulti 2 User Manual

Modbus/TCP
OperatingManualCommunicationinterfaces
1002971EN03
56
Register
(3x,4x)
Coil/
DiscreteInput
(0x,1x) Content HighByte LowByte
0 15...0 Stateofvirtualinputs
0...15
i15…i8 i7…i0
1 31...16 Stateofvirtualinputs
16...31
i31…i24 i23…i16
2 47...32 Stateofvirtualinputs
32...47
i47…i40 i39…i32
3 63...48 Stateofvirtualinputs
48...63
i63…i56 i55…i48
4 79...64 Stateofvirtualinputs
64...79
i79…i72 i71…i64
5 95...80 Stateofvirtualinputs
80...95
i95…i88 i87…i80
6 111...96 Stateofvirtualinputs
96...111
i111…i104 i103…i96
7 127...112 Stateofvirtualinputs
112...127
i127…i120 i119…i112
ThetablebelowdescribestheModbus/TCPdataareasthatcontainthestatesofthevirtual
outputsofthePNOZmulti2.
RelevantareasforthedataaredefinedintheModbus/TCPdataareasDiscreteInputs(1x)
andInputRegister(3x).Readaccessisavailabletothesedataareas.
Register
(3x)
DiscreteInput
(1x) Content HighByte LowByte
512 8207...8192 Stateofvirtualoutputs
0...15
o15…o8 o7…o0
513 8223...8208 Stateofvirtualoutputs
16...31
o31…o24 o23…o16
514 8239...8224 Stateofvirtualoutputs
32...47
o47…o40 o39…o32
515 8255...8240 Stateofvirtualoutputs
48...63
o63…o56 o55…o48
516 8271...8256 Stateofvirtualoutputs
64...79
o79…o72 o71…o64
517 8287...8272 Stateofvirtualoutputs
80...95
o95…o88 o87…o80
518 8303...8288 Stateofvirtualoutputs
96...111
o111…o104 o103…o96
519 8319...8304 Stateofvirtualoutputs
112...127
o127…o120 o119…o112
AwatchdogcanbeactivatedinControlRegister255.
IfnoinputbitsaresetbyaModbus/TCPsubscriberwithinthepresettime,thePNOZmulti2
willsettheinputbitsto"0".
