Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
76
Processdata Tables
I/OLEDs 24...27 21 11 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2002 73...76
Outputs 4...7 0x2002 77...80
SystemLEDs 8...10 0x2002 81...83
I/OLEDs 12...27 0x2002 85...100
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1114...1115 17824...17855
Outputs 4...7 1116...1117 17856...17887
SystemLEDs 8...10 1118...1119 17888...17911
I/OLEDs 12...27 1120...1127 17920...18047
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 6 0...3
Outputs 4...7 6 4...7
SystemLEDs 8...10 6 8...10
I/OLEDs 12...27 6 12...27
