Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
79
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2003 37...40
Outputs 4...7 0x2003 41...44
SystemLEDs 8...10 0x2003 45...47
I/OLEDs 12...27 0x2003 49...64
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1150...1151 18400...18431
Outputs 4...7 1152...1153 18432...18463
SystemLEDs 8...10 1154...1155 18464...18487
I/OLEDs 12...27 1156...1163 18496...18623
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 8 0...3
Outputs 4...7 8 4...7
SystemLEDs 8...10 8 8...10
I/OLEDs 12...27 8 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 2 6 0...3
Outputs 4...7 2 6 4...7
SystemLEDs 8...10 2 6 8...10
I/OLEDs 12...27 2 6 12...27
