Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
83
Processdata Tables
I/OLEDs 24...27 22 8 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2007 73...76
Outputs 4...7 0x2007 77...80
SystemLEDs 8...10 0x2007 81...83
I/OLEDs 12...27 0x2007 85...100
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1384...1385 22144...22175
Outputs 4...7 1386...1387 22176...22207
SystemLEDs 8...10 1388...1389 22208...22231
I/OLEDs 12...27 1390...1397 22240...22367
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 21 0...3
Outputs 4...7 21 4...7
SystemLEDs 8...10 21 8...10
I/OLEDs 12...27 21 12...27
