Chap. 5 Peripherals
The Peripherals menu includes the following sub-menus:
1)  Zone Expanders: see below.
2)  Tampers & EOLs: see below.
3) Keypads: set the no. of addressable keypads (ID 1-16). Keypad with ID no. 0 is not
supervised, nor can it be partitioned.
4) Keypads: see section 5.3, on page 27.
5) Output Expanders: set the no. of the relay output expanders.
5.1 Zone expanders
System Configuration  Peripherals  Zone Expanders
The Zone Expanders menu includes the following sub-menus:
1) Remote Expanders: set the no. of 8/16 remote zone expanders.
Each 16-zone expander is programmed as two 8-zone expanders and occupies 2
consecutive ID numbers. For example, if expander #3 is a 16-zone one, it takes
ID numbers 3 and 4 and so expander #4, the next expander will take ID number
5 (and not 4).
2)  Local Zone Expander: select if the ZEL508 local zone expander is installed.
3)  Zone Doubling: when selected the onboard zone 1-8 inputs can be used as inputs for 8
additional zones; see section 2.6.1, on page 11.
5.2 Tampers and EOLs
System Configuration  Peripherals  Tampers and EOLs
Parameter
Description
 Tamper 1
TMPR1 input is active.
 Tamper 1+EOL
TMPR1 input is EOL supervised, for detecting a short.
 Tamper 2
TMPR2 input is active.
 Tamper 2+EOL
TMPR2 input is EOL supervised, for detecting a short.
 External Siren+EOL
SIREN Ext. output is EOL supervised, for detecting cut and short.
 Internal Siren+EOL
SIREN Int. output is EOL supervised, for detecting cut and short.
 Double EOL
Two EOL resistors are used on ALL EOL supervised zone loops.
Resistor 1-2
Enter the resistors values in Ohm. The value entered is multiplied by
100. For example, when using a 2.2 k resistor, set the value to 220 .
